| SPECIFICATION | SIZE | MOBILE SCAFFOLD 12’ HEIGHT MOBILE SCAFFOLD 16’ HEIGHT MOBILE SCAFFOLD 20’ HEIGHT MOBILE SCAFFOLD 22’ HEIGHT MOBILE SCAFFOLD 25’ HEIGHT MOBILE SCAFFOLD 30’ HEIGHT MOBILE SCAFFOLD 32’ HEIGHT MOBILE SCAFFOLD 42’ HEIGHT |
|---|---|
| VERTICAL PANEL | |
| SIZE | 1500 MM- H X 1200 MM- W |
| MATERIAL | 48 MM X 25 MM DIA STEEL PIPE 1.6 MM THICK |
| SET DIAGONAL SUPPORT | |
| MATERIAL | 25 MM DIA STEEL PIPE 1.5 MM THICK |
| WORKING PLATFORM | |
| SIZE | 22” X 48” |
| LOAD CAPACITY | HAVING 300 KG LOAD CAPACITY ON EACH LEVEL |
| PLYWOOD | 17 MM THICK |
| WHEELS | NYLON WHEELS 6” DIA |
| MATERIAL | HRC STEEL THICKNESS:1.6 MM |
| GRADE | Q -195/235/345, ST: 37/52 (IMPORTED) |
| TROLLY | WORKING LOAD CAPACITY 600 KG |
| WITHOUT BASE TROLLY | WORKING LOAD CAPACITY 400 KG |
